OTA Test Enclosures, OTA Test Boxes & RF Over-the-Air Chambers

Discover LabiFix’s OTA (over-the-air) testing solutions—advanced RF shield boxes, RF shielded enclosures, and Faraday cages specifically designed for comprehensive over-the-air performance testing of wireless devices. These RF shielded test enclosures create a controlled, anechoic-like environment by blocking external EMI/RFI interference while incorporating high-performance absorber lining, enabling accurate measurement of radiated performance, antenna patterns, beamforming, TRP (Total Radiated Power), TIS (Total Isotropic Sensitivity), and throughput in real-world simulated conditions.

>90-100 dB IsolationISO 9001:2015 CertifiedCustom I/O Filters
OTA Test Enclosures, OTA Test Boxes & RF Over-the-Air Chambers - LabiFix RF Shield Box Solution
OTA Test Enclosures, OTA Test Boxes & RF Over-the-Air Chambers Solution100 MHz – 12 GHz+
EXPLORE MODEL VARIANTS & SPECIFICATIONS

OTA Test Enclosures, OTA Test Boxes & RF Over-the-Air Chambers Product Catalog

LBX1000 PORTABLE RF SHIELD BOX

LBX1000 PORTABLE RF SHIELD BOX - LabiFix RF Shield Box, front viewLBX1000 PORTABLE RF SHIELD BOX - LabiFix RF Shield Box, rear view

The LBX1000 RF Shield Box is a compact cabinet designed to accommodate testing of small or medium devices under test. The RF enclosure is constructed with high grade Enclosure and high grade RF Absorber materials, which help achieve better shielding effeteness >90dB. It comes equipped with multiple power options, ranging from AC and DC Power lines.

View Details

LBX3000 PNEUMATIC WITH DRAWER RF SHIELDED CHAMBER

LBX3000 PNEUMATIC WITH DRAWER RF SHIELDED CHAMBER - LabiFix RF Shield Box, front viewLBX3000 PNEUMATIC WITH DRAWER RF SHIELDED CHAMBER - LabiFix RF Shield Box, rear view

The LBX3000 is a high-performance pneumatic RF shielded enclosure with drawer designed for use in production environments and a wide range of industrial applications. There's a wide range of IO RF connectors, data ports, and power options, plus high grade RF absorbers that dampen the signal inside the RF chamber, so the LBX3000 RF Shield box can be customized for your needs. Engineers can use this RF box to create an inexpensive programmed test environment to isolate their device from outside interference during validation.

View Details

LBX4010 PORTABLE RF SHIELDED TEST ENCLOSURE

LBX4010 PORTABLE RF SHIELDED TEST ENCLOSURE - LabiFix RF Shield Box, front viewLBX4010 PORTABLE RF SHIELDED TEST ENCLOSURE - LabiFix RF Shield Box, rear view

The LBX4010 RF shielded Test enclosure is designed for wireless device testing, compatibility, functionality and performance.

View Details

LBX4800 RF SHIELDED TEST ENCLOSURE

LBX4800 RF SHIELDED TEST ENCLOSURE - LabiFix RF Shield Box, front viewLBX4800 RF SHIELDED TEST ENCLOSURE - LabiFix RF Shield Box, rear view

LBX4800 Reliable high RF shielding enclosure is designed to isolate and shield sensitive electronic devices from outside interference, making it ideal for wireless device testing purposes. Its rugged Enclosure construction and heavy duty hinges ensure it will last for years of use. High quality RF absorber materials, as well as various IO RF connectors, data ports, and power options, help dampen the signal inside the RF chamber. This box can be customized for various requirements. The RF box is ideal for engineers that need an inexpensive manual test environment to isolate their device from outside interference during each validation cycle.

View Details

LBX4900 RF SHIELDED TEST ENCLOSURE

LBX4900 RF SHIELDED TEST ENCLOSURE - LabiFix RF Shield Box, front viewLBX4900 RF SHIELDED TEST ENCLOSURE - LabiFix RF Shield Box, rear view

The LBX4900 Bluetooth Zigbee RF Shielded Test Enclosure is suitable for a variety of test applications, including product development, manufacturing, and quality assurance. With its maximum shielding efficiency against all types of EMI/RFI and noise, you can be confident that your measurements will be free from interference from external sources. Additionally, the LBX4900 features filtered AC power line and data filters for even superior shielding against RF interference. In addition, its robust welded construction ensures long-lasting and reliable performance.

View Details

Need an RF shield box for this application?

Share your DUT, frequency bands and I/O requirements and our engineers will recommend the right enclosure.

Talk to our engineers
About this range

An OTA test enclosure measures how a wireless device radiates and receives in free space.

LabiFix OTA test boxes combine a shielded shell with pyramidal absorber lining so TRP, TIS and antenna pattern results are not distorted by reflections or outside signals.

Our RF over the air chamber range runs from benchtop OTA test boxes to larger anechoic chambers; see mini anechoic chambers for the full anechoic line-up.

OTA Measurements Supported

  • Total radiated power (TRP) and total isotropic sensitivity (TIS).
  • Antenna efficiency and 3D radiation patterns.
  • 5G NR, LTE, Wi-Fi and Bluetooth OTA validation.

Frequently Asked Questions

What is an OTA test box?
An OTA test box is a shielded, absorber-lined enclosure in which a wireless device's radiated performance is measured without influence from external signals.
