LBX5000 RF Shield Box

Introducing the LBX5000 RF Shielded Test Enclosure, our wireless device shielding solution is a welded construction designed for performing EMC/EMI/RF testing and measurement in a variety of applications. The shielded enclosure is constructed with superior Enclosure and High Grade RF Absorber material helps reduce signals inside the chamber and can be customized for various requirements. A durable welded Enclosure enclosure is complemented by an EMI filter on the data ports and a Double contact RF gasket system to provide superior Shielding in the field. The shielding enclosure is designed to provide optimum performance for all types of RF testing in a variety of applications.

Dimensions
Exterior (H x W x D)
19" (H) x 25" (W) x 25" (D)
Interior (H x W x D)
17" (H) x 23" (W) x 23" (D)
Shielding Effectiveness
  • > 85 dB @ 100 MHz ~ 1 GHz
  • > 95 dB @ 1 GHz ~ 3 GHz
  • > 90 dB @ 3 GHz ~ 6 GHz
  • > 85 dB @ 6 GHz ~ 12 GHz
Call Consultation

Solutions & Benefits

Excellent shielding performance (> 85–100 dB across broad frequency spectrum)

Completely Customizable Shielded Enclosure tailored to DUT requirements

High Performance Pyramidal RF Microwave Absorber lining

User Defined & Interchangeable I/O Connector Interface options

Rugged Industrial Welded Aluminum / Steel Construction

EMI / RFI filtered Data Ports & Power Line Penetrations

RF Fitted Double-Lip Gasket Sealing System

Powered by AC / DC Power Filter lines with surge suppression

Lightweight Rack Mountable (19-inch) or Tabletop Footprint Options

High performance shielded honeycomb Air Vents for optimal cooling

LBX5000 — Exterior Mechanical Dimensions (3-View Orthographic CAD)
Units:
25"(EXTERIOR WIDTH)19"(EXTERIORHEIGHT)FRONT VIEW25"(EXTERIOR DEPTH)SIDE VIEW25"(EXTERIOR WIDTH)25"(EXTERIORDEPTH)TOP VIEWDIMENSIONS ARE IN INCHES (IN)
Exterior Envelope: 25" (W) × 19" (H) × 25" (D)Labifix Precision Engineering • 3rd Angle Orthographic Projection
LBX5000 — Interior DUT Working Chamber Dimensions (RF Absorber Cavity)
Units:
23"(INTERIOR WIDTH)17"(INTERIORHEIGHT)INTERIOR FRONT VIEW23"(INTERIOR DEPTH)INTERIOR SIDE VIEW23"(INTERIOR WIDTH)23"(INTERIORDEPTH)INTERIOR TOP VIEWDIMENSIONS ARE IN INCHES (IN)
Interior Working Volume: 23" (W) × 17" (H) × 23" (D)RF Pyramidal Microwave Absorber Lining Boundary
