RF SHIELD BOX

LBX1050 RF Shield Box

The LBX1050 isolate RF signals when you're working with wireless devices and other electronics. You can customize the shielded enclosure to fit your needs, and if heat is a concern, there are shielded air vents that keep things cool without compromising isolation. It's ideal for validation, development, or production testing—basically anywhere you need repeatable, reliable results in an RF test setup.

Dimensions
Exterior (H x W x D)
12" (H) x 17" (W) x 15" (D)
Interior (H x W x D)
10" (H) x 15" (W) x 13" (D)
Shielding Effectiveness
  • > 85 dB @ 100 MHz ~ 1 GHz
  • > 95 dB @ 1 GHz ~ 3 GHz
  • > 90 dB @ 3 GHz ~ 6 GHz
  • > 85 dB @ 6 GHz ~ 12 GHz
Call Consultation

Solutions & Benefits

Excellent shielding performance (> 85–100 dB across broad frequency spectrum)

Completely Customizable Shielded Enclosure tailored to DUT requirements

High Performance Pyramidal RF Microwave Absorber lining

User Defined & Interchangeable I/O Connector Interface options

Rugged Industrial Welded Aluminum / Steel Construction

EMI / RFI filtered Data Ports & Power Line Penetrations

RF Fitted Double-Lip Gasket Sealing System

Powered by AC / DC Power Filter lines with surge suppression

Lightweight Rack Mountable (19-inch) or Tabletop Footprint Options

High performance shielded honeycomb Air Vents for optimal cooling

LBX1050 — Exterior Mechanical Dimensions (3-View Orthographic CAD)
Units:
17"(EXTERIOR WIDTH)12"(EXTERIORHEIGHT)FRONT VIEW15"(EXTERIOR DEPTH)SIDE VIEW17"(EXTERIOR WIDTH)15"(EXTERIORDEPTH)TOP VIEWDIMENSIONS ARE IN INCHES (IN)
Exterior Envelope: 17" (W) × 12" (H) × 15" (D)Labifix Precision Engineering • 3rd Angle Orthographic Projection
LBX1050 — Interior DUT Working Chamber Dimensions (RF Absorber Cavity)
Units:
15"(INTERIOR WIDTH)10"(INTERIORHEIGHT)INTERIOR FRONT VIEW13"(INTERIOR DEPTH)INTERIOR SIDE VIEW15"(INTERIOR WIDTH)13"(INTERIORDEPTH)INTERIOR TOP VIEWDIMENSIONS ARE IN INCHES (IN)
Interior Working Volume: 15" (W) × 10" (H) × 13" (D)RF Pyramidal Microwave Absorber Lining Boundary
