LBX5250 RF Shield Box
LBX5250 is suited to engineering teams looking for dependable RF isolation without being locked into a single test configuration. Its configuration can bring together Completely Customizable Shielded Enclosure and High performance shielded Air Vents for adequate air flow so engineers can balance shielding, connectivity and access without forcing the DUT into a fixed setup. That makes it a natural fit for a rf boxes, this model can be assessed as a configurable RF isolation platform, where a defined RF environment can help engineers work with greater consistency. As a RF test enclosure, LBX5250 can be configured around the DUT and the way it needs to be tested
- > 85 dB @ 100 MHz ~ 1 GHz
- > 95 dB @ 1 GHz ~ 3 GHz
- > 90 dB @ 3 GHz ~ 6 GHz
- > 85 dB @ 6 GHz ~ 12 GHz
Solutions & Benefits
Excellent shielding performance (> 85–100 dB across broad frequency spectrum)
Completely Customizable Shielded Enclosure tailored to DUT requirements
High Performance Pyramidal RF Microwave Absorber lining
User Defined & Interchangeable I/O Connector Interface options
Rugged Industrial Welded Aluminum / Steel Construction
EMI / RFI filtered Data Ports & Power Line Penetrations
RF Fitted Double-Lip Gasket Sealing System
Powered by AC / DC Power Filter lines with surge suppression
Lightweight Rack Mountable (19-inch) or Tabletop Footprint Options
High performance shielded honeycomb Air Vents for optimal cooling
Get in Touch with Engineering
Have a custom specification or specific testing requirement? Contact our RF engineering team for custom dimensions and filter configurations.
