LBX4500 LTE UE SIGNALING CONFORMANCE TESTING SHIELD BOX

LTE UE SIGNALING CONFORMANCE TESTING SHIELD BOX

The LBX4500 RF Shielded Test Enclosure supports wireless communication technologies such as 3G, 4G, 5G LTE and Wi-Fi 802.11a/b/g/n/ac/n MIMO and rf electronics. Also, it can be completely customizable, allowing users to choose from a wide range of I/O connectors and enclosures, as well as an array of options for power and  data ports. The RF shielded enclosure is constructed with superior steel and High Grade RF Absorber materials helps dampen signals inside the RF chamber and can be customized for various requirements. The interior space inside the unit allows for larger devices to be tested while still providing high shielding effectiveness of >100dB.

Our Solutions & Benefits
  • Excellent shielding performance
  • Completely Customizable Shielded Enclosure
  • High Performance RF Absorber lining
  • User Defined & Interchangeable I/O Connector options
  • Rugged Welded Construction
  • EMI filters on Data Ports
  • RF Fitted Gasket System
  • Powered by AC / DC Power Filter lines
  • Lightweight Rack Mountable or Tabletop Options
  • High performance shielded Air Vents for adequate air flow
Highlights

SHIELDING EFFECTIVENESS (ISOLATION)

DIMENSION

  • 95dB@1GHz
  • 90dB@3GHz
  • 85dB@6GHz
  • Exterior:26"H x 17"W x 22"D
  • Interior:24"H x 15"W x 20"D

Download Datasheet

Need more help?

We’re happy to assist you. Talk to experts now.

Customer Services

+91 80-79690756

Write to us

business@labifix.com

LBX4500 Mobile Phone Testing Shielding Box
LBX4500 Mobile Phone Testing Shielding Box
LBX4500 Mobile Phone Testing Shielding Box
LBX4500 Mobile Phone Testing Shielding Box
TECHNOLOGIES SUPPORT
  • Supports Current and future wireless communication technologies such as 3G, 4G, 5G LTE
  • Wi-Fi 802.11 - all series
  • Wi-Max, GNSS, Bluetooth
  • EMI, RFI test
  • Device Testing, over the air measurements, Pre-compliance
  • R&D, Product verification, Performance reliability, Quality
LBX4500 Mobile Phone Testing Shielding Box
USER-DEFINED - I/O OPTION
  • Filtered Ethernet - 10M, 100M, 1G
  • Filtered USB 2.0 & 3.0
  • AC / DC Power filter
  • Signal transmission RF connectors​
  • RF Ports: SMA, SMB, BNC, TNC, UHF.
  • Fiber optics: ST Waveguide
  • Data: DB9, DB15, DB25, DB50, RJ11
  • Filtered HDMI, VGA & Audio Ports
  • Air ventilation with AC or DC fan
  • High performance shielded Air Vents
LBX4500 Mobile Phone Testing Shielding Box
